RYZ3N SysProfile
Code name
Pinnacle Ridge
Architecture
1 CPU - 8 Cores - 16 Threads
Revision
B2
Technology
12nm (12LP FinFET)
Family / Model / Stepping
Zen+
Socket
AM4 (PGA)
Core frequency
3700 MHz (4300 MHz Turbo)
Level 1 cache
768KB
Level 2 cache
4MB (8x 512kB)
Level 3 cache
16MB (2x 8MB)
Cooling
Air (be quiet!® Dark Rock 4)
Chipset
AMD X470
BIOS version
1.52
Expansion slots
2x PCIe 3.0 x16 (1x x16, 1x x8), 4x PCIe 2.0 x1, 1x M.2/M-Key (PCIe 3.0 x4/SATA, 22110/2280/2260/2242/2230), 1x M.2/M-Key (PCIe 2.0 x2/SATA, 2280/2260/2242/2230)
Additional
4x USB 3.0, 4x USB 2.0, 6x SATA 6Gb/s (X470), 1x seriell, 1x TPM-Header
Cooling
Passive
2 x 16384 MB G.Skill Trident Z RGB DIMM
Capacity
32768 MB
Type
DDR4-3200 DIMM 288-Pin
Timings
14-14-14-34
Real frequency
1733 MHz
Effective frequency
3466 MHz
Voltage
1.35 volts
Cooling
Passive
GPU
Manufacturer and model
SAPPHIRE™ Nitro+ Radeon™ RX Vega 56
Chip codename
Vega 10 XL "AMD GCN 5"
Technology
14 nm
Videomemory
8192 MB HBM2
Frequency
800 MHz
Bus Width
2048 bits
Bandwidth
410 GB/s
GPU frequency
1550 MHz
Shaders
3584
Bus speed
PCI-E x16 @ 16
Connectors
2x HDMI 2.0b, 2x DisplayPort 1.4
Voltage
0.95 volts
Cooling
Air
Driver
AMD Adrenalin Edition 18.9.2
Form factor
Miditower
Type
ATX
PSU
be quiet!® Straight Power 11
Power
550 W
Cooling
Air
Efficiency
90% (80 PLUS Gold, 115V), 89% (Cybenetics, 115V), 91.2% (Cybenetics, 230V)
Fans
Front
2x be quiet!® Silent Wings 3 PWM
Back
1x be quiet!® Silent Wings 3 PWM
Top
2x be quiet!® Silent Wings 3 PWM
Model
Maximum resolution
2560x1440 @ 144 Hz
Aspect Ratio
16:9
Response Time
1 ms
Brightness
350 cd/m² (avg.), 600 cd/m² (max.)
Contrast
3000:1
Connectors
2x HDMI 2.0, 1x DisplayPort 1.4
Power consumption
< 64 W, idle < 0.3 W
Other specifications
AMD FreeSync 2 HDR (48-144 Hz), LFC-Support
Solid State Disk (SSD)
Specifications
3D-NAND TLC, Samsung, 64 Layer (V-NAND v4), 512 MB Cache (LPDDR4), NVMe 1.3
Capacity
500 GB
Interface
M.2/M-Key (PCIe 3.0 x4)
Speeds
3400MB/s (reading), 2300MB/s (writing), IOPS 4K reading/writing: 370k/450k
Solid State Disk (SSD)
Specifications
3D-NAND TLC, Samsung, 64 Layer (V-NAND v4), 1024 MB Cache (LPDDR4), AHCI
Capacity
1000 GB
Interface
SATA 6Gb/s
Speeds
550MB/s (reading), 520MB/s (writing), IOPS 4K reading/writing: 98k/90k
Connection type
Cable
Download speed
400 Mbit/s
Upload speed
40 Mbit/s
Connection via
Router
ISP
Internet plan, cost
39,90 Euro
Update: 21.09.2018
Eigentlich hatte ich vor 2019 kein GPU-Upgrade mehr geplant, ein unschlagbares Angebot für eine SAPPHIRE Nitro+ Radeon RX Vega 56 hat meine Pläne aber dann doch über den Haufen geworfen. :)
Meine PowerColor Radeon RX 580 Red Devil Golden Sample hat ein neues Zuhause im PC eines guten Freundes gefunden.
Nun heißt es in Ruhe auf Navi in 2019 warten.
